Process Simulator
Response within 1 business day · Global logistics · Tender-ready docs
This board is basically structured in two sections:
A hysteresis non linear simulation, dead band and threshold it includes a digital voltmeter. The board is supplied complete with a set of stackable, plug in cables of suitable lengths and colours and with a training manual.
A linear process simulation, with two summing amplifiers, three blocks with proportional, integral, derivative transfer functions, offset and drift generators.
Power supply: ± 15Vdc, 300mA
Experiments:
Open and closed loop control of linear systems
Analysis and simulation of linear processes
System with two time constants
Calibration of a control system and criteria for the optimum setting of the PID parameters
Method of permanent oscillation
Method of damped oscillations
Behaviour of the control system against fixed or time variable disturbances
Steady state error
Analysis and study of typical nonlinear elements (saturation, threshold, hysteresis)
Experimental study of the PD controller
Experimental study of the PID controller
Transfer function of the PID controllers
Experimental study of the PI controller.
